Precision Tubes For EV Lightweighting: Applications From Body Structures To Battery Systems





Vehicle weight has a direct influence on how an electric vehicle uses energy. Because the battery pack adds significant mass to the vehicle, lightweighting opportunities across the body, chassis, and supporting systems become increasingly important. Reducing unnecessary weight can help improve energy efficiency and vehicle dynamics while supporting the overall performance targets of an EV.



However, EV lightweighting is not simply a matter of replacing steel with a lighter material. Automotive components still need to meet requirements for strength, stiffness, crash performance, durability, dimensional accuracy, and manufacturability. For OEMs and Tier 1 suppliers, the practical challenge is to reduce mass while maintaining the performance and production requirements of each application.



This makes component-level engineering important. A tube can be optimized through material grade, wall thickness, cross-section, geometry, and manufacturing process. The right combination can provide the required performance with an efficient use of material, making precision tubes relevant to a range of EV structural and functional applications.





Precision tubes offer a useful balance between structural performance, dimensional control, and manufacturing flexibility. Unlike a generic tube specification, an automotive tube solution is defined by the requirements of the finished component. Material selection, tube geometry, wall thickness, and downstream processing all influence the final result.



Material Selection



The appropriate material depends on the application's strength, weight, corrosion resistance, forming, and operating requirements. Automotive tube applications may use carbon steel, alloy steel, stainless steel, or aluminum, depending on the component and its performance targets. High-strength steel can also support weight optimization by providing the required strength with a more efficient material design. The objective is not to select the lightest material in isolation, but to match material properties to the component's actual requirements.



Tube Geometry and Wall Thickness



Tube lightweighting can also come from optimizing the tube itself. Outer diameter, wall thickness, cross-section, length, and local geometry affect weight, stiffness, load distribution, packaging, and forming behavior. Reducing wall thickness without considering these factors can create problems in forming, dimensional stability, or structural performance. For this reason, tube design needs to be considered together with the intended application and manufacturing route.



Manufacturing Processes



Processing can turn a standard tube into a component designed around a specific vehicle application. Bending, hydroforming, tube end forming, laser cutting, stamping, and welding can be used individually or in combination to achieve the required geometry, interfaces, and assembly conditions. This can also reduce unnecessary material or secondary components when the tube is designed and processed as an integrated part.





The role of tubes in EV lightweighting extends beyond a single vehicle system. They can be used in structural components that carry or distribute loads, as well as functional components that need accurate routing and reliable assembly. The following applications illustrate where precision tube design and processing can create practical value.



Side Impact Beams



Side impact beams contribute to occupant protection by reinforcing the vehicle's side structure. The component needs to balance crash performance, stiffness, weight, and available package space. For EV platforms, side structure design also needs to be considered in relation to the battery pack and surrounding body structure.



CBIES supports tube-based side impact beam applications with precision tube supply and downstream processing capabilities. Depending on the design, processes such as bending, forming, laser cutting, and welding can be combined to produce application-specific geometries while maintaining dimensional consistency for subsequent assembly.



⊙ Related Reading:

• How Do Side Impact Beams Work? | Mechanics & Safety Guide
• What Materials Are Used in Car Side Impact Beams? Structure & Safety Explained
• Side Impact Beams in Car Doors: Materials, Standards & Supplier Guide | CBIES





Cross Car Beams



Cross car beams provide structural support across the vehicle and can integrate with the instrument panel, steering column, and other vehicle systems. Their geometry and mounting interfaces make dimensional accuracy and repeatable forming important considerations.



CBIES can supply precision tubes and processed tube components for cross car beam applications, with capabilities including bending, forming, cutting, and welding. By controlling tube dimensions and processing consistency, the component can be manufactured to the customer's specified geometry, mounting points, and production requirements.





Seat Structures



Seat structures are another area where tube design can contribute to vehicle weight optimization without removing the structural functions required by the seat system. Typical requirements include strength, repeatable bending, dimensional consistency, weldability, and accurate interfaces for assembly.



CBIES supports seat system components. Bending, stamping, laser cutting, and welding can be combined according to the component design, helping customers move from tube material to production-ready structural parts.





Battery Pack Brackets



Battery pack brackets support the positioning, fastening, and structural integration of battery-related components. Although individual brackets are relatively small compared with the complete battery pack, their material usage, geometry, and manufacturing method can contribute to the overall weight and packaging efficiency of the vehicle.



CBIES manufactures battery pack brackets and related tube-based metal components according to customer drawings and application requirements. Bending, laser drilling, stamping, and welding can be combined to achieve the required mounting geometry, dimensional accuracy, and assembly interfaces.





Automotive A/C Lines



Not all lightweighting applications are structural. Automotive A/C lines are functional tube components used to route refrigerant through the vehicle air-conditioning system. Their design must accommodate limited installation space, routing requirements, connection points, and system performance requirements.



For A/C line applications, tube diameter, wall thickness, bending accuracy, and dimensional consistency are important to achieve the required routing and reliable connections. CBIES can support customized tube processing and forming requirements for automotive A/C line applications, helping customers develop tubes around their specified geometry and installation conditions.







A lightweight tube component is only useful when its design can be translated into a stable production process. For OEM and Tier 1 programs, the material and geometry need to work together with forming, joining, inspection, and production requirements.



Material and Strength Requirements



Material grade should be selected according to the component's actual load, environment, forming requirements, and target weight. For some applications, high-strength steel can support a thinner-wall design; for others, aluminum or another material may be appropriate. The correct choice depends on the complete application rather than weight alone.



Wall Thickness and Tube Geometry



Wall thickness reduction needs to be evaluated together with stiffness, strength, forming behavior, dimensional stability and joining requirements. Similarly, changing the tube diameter or cross-section can affect packaging and load distribution. These parameters need to be considered before the production process is finalized.



Tube Forming and Processing



The manufacturing route should match the required component geometry. Bending can create application-specific routing and shapes; hydroforming can support more complex profiles; tube end forming can prepare connection areas; laser cutting can create accurate openings and interfaces; stamping and welding can support component integration and assembly.



CBIES combines precision tube supply with these downstream capabilities to support both tube-only requirements and processed tube component projects. This allows the manufacturing approach to be considered together with the customer's component design rather than treating the tube as an isolated raw material.



Dimensional Accuracy and Production Consistency



For automotive production, a lightweight design must also be repeatable. Consistent tube dimensions, forming results, cut features, and welded interfaces are important for assembly and quality control. CBIES applies IATF 16949 quality process controls to support the dimensional and consistency requirements of OEM and Tier 1 programs.





EV lightweighting is ultimately an engineering optimization task. The right tube solution depends on the material, tube dimensions, wall thickness, geometry, forming process, joining method, and production requirements considered together.



For OEM and Tier 1 customers, CBIES provides precision metal tubes and processed tube components for structural and functional automotive applications. From raw tube supply to bending, hydroforming, tube end forming, laser cutting, stamping, and welding, the manufacturing route can be developed around the customer's drawing, specification, and application requirements.
